| Quantity: | |
|---|---|
GVT800 is a GPS/GPRS vehicle tracker, it is focusing on heavy-duty locomotives, long-distance buses, school buses and fleet management.
The GVT800 has a built-in terminal, it support a GPS module and a mobile communication module, which is used to send the positioning data obtained by the GPS module to the designated mobile phone via SMS.
You can directly open the link to view the corrected target position.
At the same time, the data can be sent to the server on the Internet via GPRS, so that the terminal can be inquired, monitored and managed on the computer.
Project | specifications |
Input voltage | DC 9-33V/1.5A |
Built-in battery | Rechargeable lithium battery 750mAH(3.7V). |
Volume | 84 x 66 x 30mm |
Weight | 45g |
Operating temperature | -20 to 55 |
GSM Module | Four-band GSM 850/900/1800/1900MHz |
GPS chip | The latest Ublox chip |
GPS sensitivity | - 160DB |
GPS frequency | L1,157.42MHz |
C/A code | 1.023mhz chip rate |
Channel | 50 |
Position accuracy | slt;10M, 2D RMS |
Speed accuracy | 0.1m/s |
Time Accuracy | Satellite time 1 microsecond synchronization |
Average | 0.1 seconds with the new time |
Hot starts | An average of 1 second |
Warm starts | An average of 3 seconds |
Cold starts | An average of 37 seconds |
The maximum height | 18,000 meters |
Maximum speed | 500m/s |
Maximum acceleration | less than 4g |
Work Standby | Personal mode standby for 10-12 days and car mode standby for 12 hours |
LED lights | Show power,GPS, GSM, and battery status |
Key On | Key,sos button |
Interface | 3 digital outputs 3 digital inputs 2 analog inputs 4 RS232 interfaces 1 RS485 interface |
Support The Following Platform
